Citroen C2 1.4 HDI SID 806
read/wrtite Full system 13.5V
Egr off ok
Stage 1 ok
with KT200

KT200 II read/write ecu vag Delphi dcm 6.2 via OBD 100% ok, Voltage is Important! 13.5V, voltage stabilizer is important with every job.
if you want to be more at ease with kt200ll with the latest update, read r/d files on counter and then write it in obd with all the modifications.Use load stabilizer in writing, because it will take 20m to type.


KT200II Read/write Dcm 3.7 ap Kia Rio JTAG Mode.

I worked on a Marelli 9DF ECU, HW001, I did a VR read and also a bench read—both worked fine, and the write was successful.
On HW002, I did a bench read and write, and it was also successful.
When you have read in bench, the write can be done either on bench or in the car via OBD.

do a lot of edc17
Delphi ecus....sid
RW about 100 ecus all nice
need internet and a good power supply.

VW California T6 Delphi DCM6.2 via OBD VR
Read 1 min
Write 15min
CKS by the tool
using kt200II

KT200II read/write Mercedes Benz CRD2.10  boot mode perfectly.

Kt200 Ford Mondeo 1.6TDCi obd read ok write Boot mode.

KT200 II read and write sid807evo via OBD OK.

KT200 II Read and Write Fiat Scudo 2.0 HDI Delphi DCM 3.5 via OBD.

Dcm6.2 yes via obd
Edc17cp20 bench mode

KT200 program the Denso D5E1C bench mode.

VW Sharan 2012 2.0 tsi Med17.5.2
R/W ok
chk ok
with KT200II

KT200 read and write renesas boot mode.

KT200 Read and write Citroen Bosch MD1CS003 on Bench.

KT200II Read and write FAW MD1CE100, DTC OFF, ECU data rapair.

Opel insignia 2.0 edc17c19 R/W  ok, chk ok in bench, with KT200 II.

KT200 read and write Nissan DieSel UD GK4 Jtag mode.

KT200 read and write DCM 7.1B PSA on Bench.

KT200 read and write Peugeot MD1CS003 on Bench.
